NOVARIONS VACCORE is a high-performance conical ribbon vacuum dryer engineered for efficient and gentle drying, mixing and controlled discharge of powders, crystals, granules and wet filter cakes. The optimized conical vessel, close-clearance ribbon geometry and jacketed construction promote continuous product movement across the heated surface, delivering efficient heat transfer and uniform drying under vacuum with reduced thermal exposure.
The Shiv Shakti Special Ribbon Design combines optimized pitch, angle and clearance with bidirectional rotation to provide effective forward mixing and controlled reverse discharge. Single- and double-ribbon configurations, optional centre auger and Product Circulation Guide can be selected according to product characteristics and process requirements. The design focuses on high heat-transfer efficiency, low product retention, reduced dead zones and smooth discharge, making VACCORE suitable for demanding pharmaceutical, API, specialty chemical, agrochemical, food and nutraceutical applications.
Sizes
Materials of
Coatings | MODEL | NOMINAL VOLUME | CONE DIAMETER | VESSEL HEIGHT | DISCHARGE CLEARANCE | DRIVE | APPROX. OVERALL HEIGHT* |
| CRVD/50 | 50 L | 600 mm | 575 mm | 500 mm | 1 HP | 1,300 mm |
| CRVD/100 | 100 L | 750 mm | 725 mm | 500 mm | 2 HP | 1,500 mm |
| CRVD/500 | 500 L | 1,300 mm | 1,250 mm | 600 mm | 5 HP | 2,450 mm |
| CRVD/1000 | 1,000 L | 1,625 mm | 1,565 mm | 600 mm | 7.5 HP | 2,900 mm |
| CRVD/2000 | 2,000 L | 2,050 mm | 1,975 mm | 700 mm | 10 HP | 3,500 mm |
| CRVD/3000 | 3,000 L | 2,350 mm | 2,260 mm | 700 mm | 15 HP | 3,850 mm |
| CRVD/5000 | 5,000 L | 2,800 mm | 2,675 mm | 750 mm | 20 HP | 4,500 mm |
| CRVD/6000 | 6,000 L | 2,950 mm | 2,845 mm | 750 mm | 25 HP | 4,750 mm |
| CRVD/7000 | 7,000 L | 3,100 mm | 2,995 mm | 750 mm | 30 HP | 5,000 mm |
| CRVD/10000 | 10,000 L | 3,500 mm | 3,375 mm | 750 mm | 40 HP | 5,500 mm |
| Parameter | Indicative Range |
|---|---|
| Operating Mode | Batch |
| Drying Principle | Vacuum Contact Drying |
| Mixing | Ribbon Agitation |
| Product Form | Powder / Crystal / Granule / Filter Cake / Cohesive Solids |
| Heating Medium | Steam / Hot Water / Thermal Oil |
| Drying Temperature | Application dependent |
| Vacuum | Application dependent |
| Rotation | Variable speed |
| Product Discharge | Bottom / Central |
| Particle Size | Application dependent |
| Drying Time | Product dependent |
| Operating Pressure | Vacuum / optional pressure-rated design |
| Atmosphere | Air / Nitrogen / Inert Gas |
